Product Application
1) Railways, power and telecommunication pole routes.
2) Can be used in areas suffered from frequent lightning.
3) Ideal for transmission lines with high electrical field strength.
4) Suitable for installation on poles and on the power distribution network.
5) Aerial self-supporting applications at short, medium and long span distances.
Features
1) Good mechanical and temperature performance
2) Large span with the largest span of over 1000m.
3) Reliable performance of moisture-proof and waterproof
4) Central strength member FRP gives high tensile strength
5) PE or AT sheath ensures safety of cable in high voltage environment
6) All-dielectric structure and light weight provide easy installation andgood electromagnetic resistance.
7) Prevent birds from pecking, Prevent rats from biting
The Order Information
1) Tight sleeve material type: V-PVC H-LSZH Y-Hytrel N-Nylon E-ETFE
2) FiberType: B1.3 B6a1 B6a2 B6b3 A1a A1b BIOM2 BIOM2+ BIOM3 BIOM4 BIOM5
3) Jacket Material: Polyvinyl chloride(PVC), Low smoke zero halogen(LSZH),
Therm oplatic polyurethane(TPU). or other contracted material
4) Jacket color: (Including color of fiber) Meets the requirements of relevant standards, or other contracted color
5) Cable Dimension: The nominal cable dimension or other contracted dimension
6) Delivery Length: 1KM or 2KM or other contracted length
7) Other Requirements: Other contracted special reques
